雙室低壓滲碳?xì)獯阏婵諣t

Double chamber vacuum low pressure carburizing gas quenching furnace

應用簡介/Application

真空雙室低壓滲碳?xì)獯銧t，具有滲碳、氣淬和加壓氣冷多種功能。主要用來對模具鋼、不銹鋼、高速鋼、高合金鋼工模具、淬火、退火、回火以及對中、低碳合金鋼進行滲碳淬火，多種真空熱處理工藝。可以實現一次強滲碳、脈沖滲碳等滲碳方式工藝。

The vacuum double-chamber low pressure carburizing gas quenching furnace has many functions of carburizing, gas quenching and pressure air-cooling, is mainly used for carburizing and quenching the die steel, the stainless steel, the high-speed steel, the high alloy steel tool, the quenching, the annealing, the tempering and the centering and low-carbon alloy steel, and a plurality of vacuum heat treatment processes. Can realize the process of one-time high-carburizing, pulse carburizing and so on.

產品特點/characteristic

1.專用的真空低壓滲碳模擬軟件，智能高效

Special vacuum low-pressure carburizing simulation software, intelligent and efficient

2.采用高效方形換熱器， 冷卻速度提高80%。

The cooling rate is increased by 80% by using high efficiency square heat exchanger.

3.采用雙風機對流均勻冷卻

Uniform cooling with double-fan convection。

4. 加熱元件沿加熱室圓周360度均勻布置，溫度均勻性高

The heating element is evenly arranged along the circle of the heating chamber at 360 degrees, and the temperature uniformity is high.

5.加熱室采用外絕緣結構，減少杜絕滲碳炭黑污染

The heating chamber adopts the external insulation structure to reduce the pollution of the carburized carbon black.

6.采用碳?xì)譃榧訜崾腋魺釋?，使用壽命長

The carbon felt is used as the heat-insulating layer of the heating chamber with long service life

7.滲碳?xì)怏w噴嘴沿加熱室圓周及前后均勻布置，滲碳層厚度均勻

Carburizing gas nozzles are uniformly arranged around and before and after the heating chamber, and the thickness of carburized layer is uniform.

8.滲碳工件變形小，生產效率高，使用成本較氣體滲碳節能40%以上

The Carburizing workpiece has the advantages of small deformation, high production efficiency and more than 40% energy saving compared with gas Carburizing.。

9.編程工藝靈活輸入，機械動作穩定可靠，故障自動報警/顯示

Flexible input of programming process, stable and reliable mechanical action, automatic alarm / display of fault

10.氣淬風機變頻驅動，對流加熱功能可選、九點測溫可選

Frequency conversion drive of gas quenching fan, optional convective heating function,optional temperature measurement at nine points

11.全智能化工業計算機控制系統并有一套手動操作系統

Fully intelligent chemical industry computer control system and a manual operating system。

12.操作簡潔、編程工藝靈活輸入、機械動作穩定可靠

Simple operation , the programming process is flexible input, the mechanical action is stable and reliable,

13.手動/半自動/自動 故障自動報警/顯示

Manual / semi-automatic / automatic fault automatic alarm / display

產品規格/product specifications

以上參數可根據工藝要求調整，不作為驗收依據，具體以技術方案和協議為準

The above parameters can be adjusted according to the process requirements, not as a basis for acceptance, the specific technical plan and agreement shall prevail

配置選擇/Configure select
